Aimtec Adds 3 & 5W DC/DC Converters to its Lineup


Montreal, Canada – The new AM3DG-NZ & AM5TG-NZ series feature I/O Isolation up to3500VAC/6000VDC with ultra-low Isolation Capacitance

The new AM3DG-NZ series in SIP7 package (19.50 x 9.80 x 12.5 mm) and AM5TG-NZ in DIP 24 package (31.60 x 20.30 x 10.20 mm) both feature Continuous Short Circuit Protection and the latter also features Output Over Voltage Protection. Both series are specially designed to offer a High I/O Isolation, achieving values of up to 3500VAC/6000VDC with an ultra low Isolation capacitance to effectively power IGBT Drivers while having a low RF impact.

The AM3DG-NZ series supports a nominal input voltage of 15VDC which it then converts into dual output voltages of -4 & +20 VDC. Operating in an extended temperature range of -40°C to +105°C, the series only starts experiencing derating at +85°C.

The AM5TG-NZ, with nominal input voltages of 12 & 24VDC and dual output voltages of -9 & +15VDC operates within an ambient temperature range of -40°C to +85°C with no derating up to +71°C.

Samples are available from stock and can be ordered immediately from any of Aimtec’s global network of Franchised Distributors. Visit www.aimtec.com for more product information or to locate your nearest Distributor.

Datasheets:

AM3DG-NZ

AM5TG-NZ
