Catalog v19 Final - page 30

Series NRND MTBF Hrs Op temp Derating FL Input VoltageRange %
Voltage
Accuracy %
Line
Regulation %
Load
Regulation %
Ripple & Noise
mV p-p
Switching Freq.
Typ. KHz
AM10TW-Z 1,000,000 -40 to +85C 60C 4:1 ±1.2 ±0.5 ±1 85 270
AM10TW-IZ 700,000 -40 to +75C 50C 4:1 ±2 ±0.5 ±0.5 80 300
AM10EW-Z 1,121,000 -40 to +85C 4:1 ±1 ±0.5 ±0.5 75 300
AM10EW-NZ 1,000,000 -40 to +85C 71C 4:1 ±1 ±0.2 ±0.5 100 350
AM15CW-Z 560,000 -40 to +85C 55C 4:1 ±1 ±0.2 ±0.5 100 375
AM15CW-FZ 1,580,000 -40 to +85C 63C 4:1 ±1 ±1 ±1 80 330
AM15E-Z 1,121,000 -40 to +85C 70C 2:1 ±1 ±0.5 ±0.5 100 200
AM15E-IZ 800,000 -40 to +85C 50C 2:1 ±2 ±0.5 ±0.5 120 200
AM15EW-Z 1,121,000 -40 to +85C 60C 4:1 ±1 ±0.5 ±0.5 75 300
AM15EW-IZ 800,000 -40 to +85C 50C 4:1 ±2 ±0.5 ±0.5 120 200
AM15EW-NZ 1,000,000 -40 to +85C 60C 4:1 ±3 ±0.5 ±1 100 300
AM20CW-Z 560,000 -40 to +75C 55C 4:1 ±1 ±0.5 ±0.5 100 330
AM20CW-FZ 350,000 -40 to +85C 60C 4:1 ±1 ±1 ±1 80 330
AM20EW-Z 560,000 -40 to +85C 65C 4:1 ±1 ±0.5 ±0.5 75 330
AM20EW-NZ 1,000,000 -40 to +85C 55C 4:1 ±3 ±0.2 ±0.5 100 270 & 300
AM30EW-Z 450,000 -40 to +85C 50C 4:1 ±1 ±0.2 ±0.5 100 330
AM30EW-NZ 1,000,000 -40 to +85C 55C 4:1 ±1 ±0.2 ±0.5 100 300
AM30K-Z 1,000,000 -40 to +85C 60C 2:1 ±5 ±5 ±0.5 75 270
AM30K-NZ 1,000,000 -40 to +85C 71C 2:1 ±1 ±0.2 ±0.5 100 300
AM30K-IZ 550,000 -40 to +85C 40C 2:1 ±2 ±0.5 ±0.5 120 250
AM40U-AZ 1,500,000 -40 to +85C 55C 2:1 ±2 ±1 ±2 75 300
AM40U-IZ 1,500,000 -40 to +75C 45C 2:1 ±2 ±0.5 ±0.5 80 250
AM40UW-Z 1,500,000 -40 to +85C 55C 4:1 ±1 ±0.5 ±0.5 150 270
AM40UW-IZ 1,500,000 -40 to +75C 45C 4:1 ±2 ±0.5 ±0.5 80 250
Product Comparisons
Detailed product information is available in the datasheets atwww.aimtec.com
