Catalog v19 Final - page 11

SERIES INPUT
(VDC)
SINGLE OUTPUT
(VDC)
DUAL OUTPUT
(VDC)
ISOLATION
(VDC) CASE SAFETY
AM4N-Z 5, 12 3.3, 5, 12, 15 5K VAC DIP24 CE
AM4T-Z 4.5-9, 9-18, 18-36,
36-72
3.3, 5, 7.2, 9, 12, 15,
18, 24
±3.3, ±5, ±7.2, ±9,
±12, ±15, ±18, ±24 1.5K, 3.5K DIP24 CE
AM4T-VZ 9-18, 18-36, 36-72 5, 9, 12, 15, 24 ±5, ±9, ±12, ±15,
±24 1.5K, 3.5K DIP24 --
AM4TW-Z 9-36, 18-72 3.3, 5, 7.2, 9, 12, 15,
18, 24
±3.3, ±5, ±7.2, ±9,
±12, ±15, ±18, ±24 1.5K, 3.5K DIP24 CE
AM4TW-RZ 9-36, 18-72 3.3, 5, 7.2, 9, 12, 15,
18, 24
±3.3, ±5, ±7.2, ±9,
±12, ±15, ±18, ±24 1.5K DIP24 CE
AM4TW-VZ 9-36, 18-72 3.3, 5, 12, 15 ±5, ±12, ±15 1.5K, 3.5K DIP24 --
AM4TW-RVZ 9-36, 18-72 3.3, 5, 12, 15 ±5, ±12, ±15 1.5K DIP24 --
4 Watt
AM6C-NZ 9-18, 18-36, 36-75 3.3, 5, 12, 15, 24 ±5, ±12, ±15, ±24 1.5K 1 x 1" --
AM6CW-FZ 9-36, 18-75 3.3, 5, 9, 12, 15, 24 ±5, ±12, ±15 1.5K 1 x 1" --
AM6CW-NZ 9-36, 18-75, 40-160 3.3, 5, 9, 12, 15, 24 ±5, ±12, ±15, ±24 1.5K 1 x 1" --
AM6G-Z 4.5-9, 9-18, 18-36,
36-75 3.3, 5, 9, 12, 15, 24 ±5, ±12, ±15 1.5K, 3K SIP8 CE
AM6GH-Z 9-36, 18-75 3.3, 5, 9, 12, 15, 24 ±5, ±12, ±15 1.5K, 3K SIP8 CE
AM6Q-Z 4.5-9, 9-18, 18-36,
36-75 3.3, 5, 12, 15 ±12, ±15 500VAC 1.7 X
1.1" --
AM6T-Z 4.5-9, 9-18, 18-36,
36-72
3.3, 5, 7.2, 9, 12, 15,
18, 24
±3.3, ±5, ±7.2, ±9, ±12,
±15, ±18, ±24 1.5K, 3.5K DIP24 CE
AM6T-VZ 9-18, 18-36, 36-72 5, 9, 12, 15, 24 ±5, ±9, ±12, ±15, ±24 1.5K, 3.5K DIP24 --
AM6TI-Z 9-18, 18-36, 36-75 3.3, 5, 12, 15, 24 ±3.3, ±5, ±12, ±15, ±24 1.5K, 3K DIP24 CE, UL
AM6T-NZ 9-18, 18-36, 36-75 3.3, 5, 9, 12, 15, 24 ±5, ±12, ±15 1.5K, 3K DIP24 CE
AM6TW-Z 9-36, 18-72 3.3, 5, 7.2, 9, 12, 15,
18, 24
±3.3, ±5, ±7.2, ±9, ±12,
±15, ±18, ±24 1.5K, 3.5K DIP24 CE
AM6TW-RZ 9-36, 18-72 3.3, 5, 7.2, 9, 12, 15,
18, 24
±3.3, ±5, ±7.2, ±9, ±12,
±15, ±18, ±24 1.5K DIP24 CE
AM6TW-VZ 9-36, 18-72 12, 15 ±12, ±15 1.5K, 3.5K DIP24 --
AM6TW-RVZ 9-36, 18-72 12, 15 ±12, ±15 1.5K DIP24 --
AM6TIW-RZ 9-36, 18-75 3.3, 5, 12, 15, 24 ±3.3, ±5, ±12, ±15, ±24 1.5K, 3K DIP24 CE, UL
AM6TW-NZ 9-36, 18-75 3.3, 5, 9, 12, 15, 24 ±5, ±12, ±15 1.5K, 3K, 6K DIP24 --
6 Watt
AM5T-Z 4.5-9, 9-18, 18-36,
36-72
3.3, 5, 7.2, 9, 12, 15,
18, 24
±3.3, ±5, ±7.2, ±9,
±12, ±15, ±18, ±24 1.5K, 3.5K DIP24 CE
AM5T-FZ 9-18, 18-36, 36-75 5, 12, 15 ±12, ±15 4K VAC DIP24 --
AM5T-VZ 9-18, 18-36, 36-72 5, 9, 12, 15, 24 ±5, ±9, ±12, ±15, ±24 1.5K, 3.5K DIP24 --
AM5TW-Z 9-36, 18-72 3.3, 5, 7.2, 9, 12, 15,
18, 24
±3.3, ±5, ±7.2, ±9,
±12, ±15, ±18, ±24 1.5K, 3.5K DIP24 CE
AM5TW-RZ 9-36, 18-72 3.3, 5, 7.2, 9, 12, 15,
18, 24
±3.3, ±5, ±7.2, ±9,
±12, ±15, ±18, ±24 1.5K DIP24 CE
AM5TW-VZ 9-36, 18-72 3.3, 5, 12, 15 ±5, ±12, ±15 1.5K, 3.5K DIP24 --
AM5TW-RVZ 9-36, 18-72 3.3, 5, 12, 15 ±5, ±12, ±15 1.5K DIP24 --
5 Watt
AM6Q-Z
1.7” x 1.1”
AM4TW-RZ DIP24
AM5TW-Z DIP24
Note: Nominal Input voltages are ±10%, unless otherwise specified.
D
C
/
D
C
C
O
N
V
E
R
T
E
R
S
11
